Rugged, Practical Design

• With no internal parts, there's nothing to wear out
• Sample compartment lifts out for easy cleaning
• Polymer construction resists corrosion from acidic or oxidizing solutions
• Navigation pad and on-screen menus are second nature to any modern user
• Compact footprint saves space in your lab
• Cuvette racks on both sides of the sample compartment help you keep track of samples
• No computer or serial cable required; Just plug it in and you're ready to measure

Optical Design Single Beam
Spectral Bandwidth ≤ 4 nm
Light Source Tungsten-halogen
Detector 2048 element CCD
Wavelength Range 340 nm – 1000 nm
Accuracy ± 2 nm
Repeatability ± 1 nm
Data interval 1 nm
Photometric Range -0.3 A to 2.5 A
Readout ABS, %T, Concentration
Accuracy ± 0.01 A at 0.3 A
± 0.05 A at 1.0 A (SPECTRONIC standard filters measured at 590 nm)
Repeatability ± 0.3 %T at 50 %T
